100pcs/Lot
DC2 2.54mm Straight Hook Horn Socket Connector 6/8/10/12/14/16/20/26/30/34P/40P mate with Flat Ribbon Cable IDC Socket
Long latch-L8.17mm
Specification
| Material | ||
| Terminals | Copper alloy | |
|
plating |
According to order request |
|
| Plastic | PBT, (UL 94V-0) | |
| Electrical | ||
| Standard | / | / |
| Rated voltage | / | / |
| Rated current | 3.0A | / |
| Wire range | / | / |
| Contact resistance | 20mΩ Max.(intial). | |
| Insulation resistance | 500MΩ Min | |
| Withstand Voltage | AC 1000V/Min | |
| Mechanical | ||
| Temperature range | -40°C~+105°C | |
| Max.Torque | / | |
| Strip length | / | |
| Size | ||
| Pitch | 2.54mm | |
| poles | 10 - 64 | |
