1pcs/lot
Main Features
- Precise induction
- Fast response speed
- Long durability
- Product shape can be customized according to customer requirements
- Product pressure point distribution can be customized according to customer requirements
- Product pressure sensing range can be customized according to customer requirements
Main Technical Data and Physical Properties
| Parameter | Specification |
|---|---|
| Thickness | 0.3mm |
| Style | Thin sheet / Film-like |
| Actuation Force | 20g |
| Pressure Range | 20g ~ 5kg, single sensing point |
| Pressure Application Method | Press |
| Resistance (unactuated) | > 20MΩ |
| Operating Temperature | -20°C ~ +65°C |
| Repeatability Accuracy | +/-5% @ 1Kg, single unit |
| Drift | -10%, 24H @ 1Kg |
| Hysteresis | 10%, 24H @ 1Kg |
| Durability | >1,000,000 cycles at 1Kg force |
| Response Time | <10 μs |
| Electromagnetic Interference (EMI) | None generated |
| Electrostatic Discharge (ESD) Sensitivity | Not sensitive |
| RoHS Compliant | (Not specified) |
