Tetrode electrode BCI Drug delivery tube integrated 16CH
The price is NOT actual price, pls kindly contact us to clarify the specification before making quotation.
Applicable situation:
Integrated the tetrode electrode with the drug delivery tube to realize the analysis of a single neuron under different pharmacological conditions, using a 0.38mm diameter outer cannula to reduce the damage caused by implantation and improve the success rate of signal acquisition.
General parameters: The tetrode electrode wire is 15/20um nickel-titanium alloy wire, the length is 5mm/8mm, and the length of the drug delivery tube is 300/500um shorter than the electrode wire.
The number of channels-4CH-32CH optional, size and other parameters can be customized according to actual needs
General parameters:
| Type： |
Tetrode electrode BCI Drug delivery |
||
| Material： | Nitinol ，15/20μm | Reference： | Include a reference electrode/wire |
| D3： | 380μm | D4： | 250μm |
| D8： | 600μm |
